-86c Chest Ult Deep Freezer, -86c Ultra Low Temperature Freezer/ Medical Freezer/Lab Freezer

-86?C Chest ULT Deep Freezer

Features

Refrigeration System

Optimized cascade refrigeration technology, SECOP compressor to reach a high efficient refrigeration effect;

Specially designed Heat Exchanger, heat transfer high efficient, save Energy;

Single Compressor efficient thermal cycle refrigeration technology, low noise, more energy efficient;

CFC-Free overall polyurethane foaming insulation;

CFC-Free refrigerant.

Temperature Control

Microprocessor control, Large LED display inner temperature clearly, and with easy viewing;

The inner temperature can be adjustable at the range of -40?C~-86?C;

Safety Control

Malfunction alarms: high temperature alarm, low temperature alarm, over temperature alarm system, set the alarm temperature as requirements;

Two alarming methods: buzzer alarming and digital flashing alarming;

Protection function: power-on delay, time between stops.

Ergonomic Design

Safety door lock, preventing unauthorized access;

Wide voltage design from 192V to 242V;

Stainless steel inner chamber, easy for clean;

Heavy type caster and locking adjustable screw, easy to move and fix.

Model: FSF-86W58 FSF-86W258 FSF-86W458
Technical Data: Cabinet Type Chest Chest Chest
Climate Class: N N N
Cooling Type: Direct cooling Direct cooling Direct cooling
Defrost Mode: Manual Manual Manual
Refrigerant: CFC-Free CFC-Free CFC-Free
Performance: Cooling performance(?C) -86 -86 -86
Temperature Range(?C): -40~-86 -40~-86 -40~-86
Control: Controller Microprocessor
Display: LED
Material: Interior stainless steel
Exterior: Galvanized steel powder coating
Electrical Data: Power Supply (V/Hz) 220/50 220/50 220/50
Power(W): 400 500 550
Dimensions: Capacity(L) 58 258 458
Net/Gross Weight(approx): 40/55 (kg) 76/93(kg) 93/110 (kg)
Interior Dimensions (W*D*H): 410?410 ?355 (mm) 780?500 ?600 (mm) 1380?500 ?660 (mm)
Exterior Dimensions (W*D*H): 670?760 ?1025 (mm) 1510?885 ?1095 (mm) 2110?885 ?1095 (mm)
Packing Dimensions (W*D*H): 750?850 ?1150 (mm) 1600?975 ?1225 (mm) 2200?975 ?1225 (mm)
Functions: High/Low Temperature Y Y Y
Sensor Error: Y Y Y
Lockage: Y Y Y
Accessories: Caster Y Y Y
Foot: N/A N/A N/A
Test Hole: N/A N/A N/A
Baskets/Inner Doors: 2/- 2/- 2/-
Temperature Recorder: Optional Optional Optional
Cryo racks: Optional Optional Optional
